Industrial Steel Bobbin for Yarn & Thread Winding
- Usage
Product Overview
Our industrial-grade steel bobbins are engineered for winding and storing high-tension yarns, threads, and technical textiles. Designed for durability and stability under high-speed operations, these bobbins are ideal for use in textile manufacturing, heavy-duty sewing, and fiber reinforcement processes. - Design history
- Spec.
48.5 O.D x 0.8 T x 420 L
49.4 O.D x 1.2 T x 420 L
48.5 O.D x 0.8 T x365 L
etc.
Inquiry
- Contact
Sales Dept.
- Tel
+82-31-351-8265
Key Features
-
Material: High-strength carbon steel or stainless steel
-
Stable Structure: Reinforced core and flanges to resist deformation during winding
-
Smooth Surface Finish: Prevents damage or snagging of delicate yarns
-
Custom Sizes Available: Flange diameter, core diameter, and winding width configurable
-
Heat & Chemical Resistant: Suitable for demanding industrial environments
Applications
-
Technical sewing thread winding (e.g. polyester, nylon, aramid)
-
Fiber reinforcement yarns (e.g. glass fiber, carbon fiber)
-
Industrial weaving and braiding prep
-
Heavy-duty textile processing and transport
Specifications
-
Flange Diameter: 200–600 mm
-
Core Diameter: 50–150 mm
-
Width (Traverse): 100–400 mm
-
Weight Load: Up to 50 kg (customizable)
-
Surface Options: Bare steel, powder coating, galvanized
Optional Features
-
Hollow core for spindle mounting
-
Center hole or drive slot options
-
Stackable or nesting design available
